CI/CD examples

Version control

basic-workflow

Build and push container

image: docker:19.03.12

services:
  - docker:19.03.12-dind

stages:
  - build

## Template for building and publishing the docker container
.build:
  stage: build
  image: docker:latest
  variables:
    HARBOR_IMAGE: "registry.services.k8s.true.nl/onboarding/app01-demo"
  before_script: &before_script_build
    - docker login -u "$HARBOR_USERNAME" -p "$HARBOR_PASSWORD" "registry.services.k8s.true.nl"
    - echo "${IMAGE_TAG}"
  script:
    - docker build --pull -t "${HARBOR_IMAGE}" .
    - docker tag "${HARBOR_IMAGE}" "${HARBOR_IMAGE}:${IMAGE_TAG}"
    - docker push "${HARBOR_IMAGE}:${IMAGE_TAG}"
    - docker push "${HARBOR_IMAGE}"

build:production:
  extends: .build
  variables:
    IMAGE_TAG: "$CI_COMMIT_TAG"
  only:
    - tags

Example provided "as-is" by prepr.io ❤

name: "Build & Deploy Production"

on:
  release:
    types: [released]

jobs:

  build:

    runs-on: ubuntu-latest

    steps:
     - name: Check Out Repo
       uses: actions/checkout@v2

     - name: Add HTTP basic auth credentials for GIT
       run: echo '${{ secrets.PAT_GITHUB }}' > $GITHUB_WORKSPACE/auth.json

     - name: SignIn Docker
       run: echo "${{ secrets.HARBOR_PASSWORD }}" | docker login ${{ secrets.HARBOR_HOSTNAME }} -u "${{ secrets.HARBOR_USERNAME }}" --password-stdin

     # Set {{folder}}, {{project}} to push to the r

     - name: Docker Meta Sign Release
       id: meta
       uses: docker/metadata-action@v3
       with:
         # Basename of the Docker Image
         images: |
           registry.services.k8s.true.nl/{{folder}}/{{project}}
         # Generate Docker tags based on the following events/attributes (default)
         tags: |
           type=schedule
           type=ref,event=branch
           type=ref,event=pr
           type=semver,pattern={{version}}
           type=semver,pattern={{major}}.{{minor}}
           type=semver,pattern={{major}}
           type=sha

     - name: Set up Docker Buildx
       id: buildx
       uses: docker/setup-buildx-action@v1

     - name: Build and push
       id: docker_build
       uses: docker/build-push-action@v2
       with:
         context: ./
         file: ./Dockerfile
         push: true
         tags: ${{ steps.meta.outputs.tags }}
         labels: ${{ steps.meta.outputs.labels }}

     - name: Remove auth.json file
       run: rm -f $GITHUB_WORKSPACE/auth.json

  deploy:

     needs: build

     runs-on: ubuntu-latest

     container: registry.services.k8s.true.nl/library/helm-push:2.0.0

     steps:

       - name: Extract Release from Ref
         id: releaseversion
         run: echo ::set-output name=VERSION::$(echo ${{ github.ref }} | cut -d / -f 3)

      # SET {{appName}} tot the Argo Project name

       - name: Argo Tag Update
         run: |
           export ARGOCD_SERVER=${{ secrets.ARGOCD_HOSTNAME }}
           export ARGOCD_AUTH_TOKEN="${{ secrets.ARGOCD_TOKEN }}"
           argocd app set "{{appName}}" -p image.tag=${{ steps.releaseversion.outputs.VERSION }}

kind: pipeline
name: default
type: kubernetes
steps:
- name: build
  image: registry.services.k8s.true.nl/library/drone-kaniko:1.0.2
  settings:
    repo: application-name-here
    registry: registry.services.k8s.true.nl/01408-fakename
    tags:
      - 'master'
    username:
      from_secret: username
    password:
      from_secret: password

Build and push Helm charts

stages:
  - helm-lint
  - polaris-audit
  - push-helm-chart

helm list:
  stage: helm-lint
  variables: {}
  image: registry.services.k8s.true.nl/library/helm-push:2.0.0
  script: |
    cd charts
    for i in `ls -d */ | cut -f1 -d'/'`
    do
            helm lint $i
    done
polaris audit:
  stage: polaris-audit
  variables: {}
  image: registry.services.k8s.true.nl/library/helm-push:testing
  script: |
    cd charts
    for i in `ls -d */ | cut -f1 -d'/'`
    do
            polaris audit --helm-chart $i --config config.yaml
    done
push chart:
  stage: push-helm-chart
  variables: {}
  image: registry.services.k8s.true.nl/library/helm-push:2.0.0
  script: |
    helm repo add k8s-true https://registry.services.k8s.true.nl/chartrepo/01408-fakename/ --username=$HARBOR_USERNAME --password=$HARBOR_PASSWORD
    helm repo update
    cd charts
    for i in `ls -d */ | cut -f1 -d'/'`
    do
            helm push $i k8s-true
    done
  only:
    - tags

Example provided "as-is" by prepr.io ❤

name: "Push to Harbor registry"

# {{chartName}} should be replaced with the folder of the chart.

on:
  push:
    branches: [ main ]
    paths:
      - 'charts/{{chartName}}/Chart.yaml'

jobs:

  push:

    runs-on: ubuntu-latest

    container: registry.services.k8s.true.nl/library/helm-push:2.0.0

    steps:
      - name: Check Out Repo
        uses: actions/checkout@v2

      - name: Install Helm Push
        run: |
          mkdir -vp /root/.helm/plugins
          helm plugin install https://github.com/chartmuseum/helm-push

      - name: Add Repo & Update local repository
        run: |
          helm repo add k8s-true ${{ secrets.HARBOR_CHART_REPO }} --username=${{ secrets.HARBOR_USERNAME }} --password=${{ secrets.HARBOR_PASSWORD }}
          helm repo update

      - name: Helm Push
        run: |
          cd charts
          for i in `ls -d */ | cut -f1 -d'/'`
          do
            helm cm-push $i k8s-true
          done

Changing argocd from ci (cli)

.argo-deploy:
  stage: argo-deploy
  image:
    name: registry.services.k8s.true.nl/library/helm-push:2.0.0
    entrypoint: [/bin/bash, -c]
  script:
    - export ARGOCD_SERVER=argocd-01408.saas.true.nl
    - export ARGOCD_AUTH_TOKEN="$ARGO_CI_TOKEN"
    - argocd app set ${BRANCH_NAME}-demo-app01 -p image.tag=${IMAGE_TAG}

argo-deploy:production:
  extends: .argo-deploy
  variables:
    IMAGE_TAG: "$CI_COMMIT_TAG"
    BRANCH_NAME: "prd"
  only:
    - tags

Example provided "as-is" by prepr.io ❤

name: "Update ArgoCD tag"

on:
  push:
    branches: [ main ]

jobs:

  deploy:

    needs: build

    runs-on: ubuntu-latest

    container: registry.services.k8s.true.nl/library/helm-push:2.0.0

    steps:

        - name: Argo Tag Update
          run: |
            export ARGOCD_SERVER=${{ secrets.ARGOCD_HOSTNAME }}
            export ARGOCD_AUTH_TOKEN="${{ secrets.ARGOCD_TOKEN }}"
            argocd app set "acc-marketing-prepr-io" -p image.tag=${{ github.sha }}

Warning

Changing the argocd spec in-cluster will take precidance over the git config. This means the values changed will be out of sync from git. While not great, we find this an acceptable trade-off for usablity. In the argoCD web interface under parameters you can view override values as they are prefixed with a 'hammer' example:


Deleting the application completely from argocd and re-syncing it after will reset the application to default settings.
